Stores icon-grid rows, named colour keys, and typed symbol rows as content. legend_render() lays out the content and fits its border at the requested physical size. The specification can later be reused for related legends.

Usage

legend_spec(
  grid,
  keys = NULL,
  symbols = NULL,
  key_columns = 1L,
  grid_title = NULL,
  group_title = NULL,
  symbol_title = NULL,
  group_key_width = 0.2375,
  group_label_gap = 0.1187,
  group_gap = 0.591,
  key_column_gap = 0.317,
  group_title_nudge = 0,
  swatch_height = 0.56,
  xlim = NULL,
  label_size = 3.634,
  label_fontface = "plain",
  marker_size = 3.717,
  dpi = 120,
  ratios = legend_ratios(),
  border = "#231F20",
  border_padding = c(0.018, 0.09)
)

Arguments

grid: A data frame from icon_grid().
keys: Named character vector of colour values. Names are key labels.
symbols: Named character vector of "line", "point", "swatch", or "text" types, or a data frame accepted by key_legend(). A text row has a label but no visible key.
key_columns: Number of colour-key columns, filled from top to bottom.
grid_title, group_title: Optional titles for the icon grid and colour keys.
symbol_title: Optional title for the symbol column. With no title the first symbol row sits on the title line, so it doubles as the column heading. With a title, the heading takes that line and the symbols start on the same rows as the icon grid and colour keys.
group_key_width, group_label_gap, swatch_height: Dimensions of the external colour keys in grid coordinates. swatch_height is a fraction of one row.
group_gap: Gap from the rightmost colour-key label to the icon grid.
key_column_gap: Gap between colour-key columns.
group_title_nudge: Horizontal adjustment to the centred group title.
xlim: Optional fixed horizontal canvas limits. NULL centres the measured content automatically.
label_size: Text size in millimetres.
label_fontface: Font face for every title and label: "plain", "bold", "italic", or "bold.italic".
marker_size: Icon size passed to geom_icon_point().
dpi: Icon rendering resolution.
ratios: Layout proportions from legend_ratios().
border, border_padding: Border colour and padding passed to legend_box(). Use border = NA to omit the border.

Value

A ggpop_legend_spec object to pass to legend_render().

Examples

grid <- data.frame(
  row = c(1, 2), col = c(1, 1),
  icon = c("square-inset", "circle-solid"),
  label = c("A", "B")
)
spec <- legend_spec(grid, keys = c(Group1 = "#1090F3", Group2 = "#DF4601"),
                    symbols = c(Frontier = "line"), key_columns = 2)
legend_render(spec, width = 7, height = 1.5)
