Animated Markov Cohort (Sick-Sicker)

This example shows how to combine a cohort Markov model with ggpop and gganimate.

The Sick-Sicker model is a common health economics model structure that simulates disease progression across multiple health states. In this example, we simulate a cohort of individuals starting at age 40 and track their transitions through the states of Healthy, Sick, Sicker, and Death until age 100. We then visualize the changing distribution of the cohort across these states over time using an animated population plot.

We simulate a Sick-Sicker model from age 40 to 100 across four states: Healthy, Sick, Sicker, and Death.

Show the code

# #* Load package functions
devtools::load_all(".")
library(ggpop)
library(ggplot2)
library(dplyr)
library(tidyr)
library(gganimate)

# -------------------------------
# 1) Cohort Markov model inputs
# -------------------------------
states <- c("Healthy", "Sick", "Sicker", "Death")
age_start <- 40
age_end <- 100
n_cycles <- age_end - age_start

# Transition probability matrix (rows = current state, cols = next state)
# Healthy -> Healthy/Sick/Sicker/Death
# Sick    -> Healthy/Sick/Sicker/Death
# Sicker  -> Healthy/Sick/Sicker/Death
# Death   -> Death (absorbing)
m_P <- matrix(
  c(
    0.85, 0.12, 0.02, 0.01,
    0.08, 0.85, 0.05, 0.02,
    0.00, 0.00, 0.95, 0.05,
    0.00, 0.00, 0.00, 1.00
  ),
  nrow = length(states),
  byrow = TRUE,
  dimnames = list(states, states)
)

stopifnot(all(abs(rowSums(m_P) - 1) < 1e-10))

# ---------------------------------
# 2) Cohort trace from age 40 to 100
# ---------------------------------
m_trace <- matrix(
  0,
  nrow = n_cycles + 1,
  ncol = length(states),
  dimnames = list(cycle = 0:n_cycles, state = states)
)

# Initial cohort distribution at age 40
m_trace[1, ] <- c(1, 0, 0, 0)

for (t in seq_len(n_cycles)) {
  m_trace[t + 1, ] <- m_trace[t, ] %*% m_P
}

# Long-format cohort proportions by age
cohort_long <- as.data.frame(m_trace) %>%
  mutate(cycle = 0:n_cycles,
         age = age_start + cycle) %>%
  pivot_longer(
    cols = all_of(states),
    names_to = "state",
    values_to = "prop"
  )

# ------------------------------------------------------
# 3) Convert each cycle's proportions to icon-level data
# ------------------------------------------------------
# process_data() samples icons within each age (high_group_var = "age")
# sample_size = 400 means each icon is ~0.25% of the cohort in each frame
set.seed(2026)
df_icons <- process_data(
  data = cohort_long,
  high_group_var = "age",
  group_var = state,
  sum_var = prop,
  sample_size = 400
) %>%
  mutate(
    age = as.integer(group),
    state = factor(type, levels = states),
    icon = case_when(
      state == "Healthy" ~ "person-walking",
      state == "Sick" ~ "person-cane",
      state == "Sicker" ~ "wheelchair",
      state == "Death" ~ "skull-crossbones"
    )
  )

# --------------------
# 4) Animated ggpop plot
# --------------------
p_anim <- ggplot(df_icons, aes(icon = icon, color = state)) +
  geom_pop(
    size = 1.1,
    arrange = TRUE,
    legend_icons = TRUE,
    seed = 2026,
    dpi = 100
  ) +
  scale_color_manual(
    values = c(
      "Healthy" = "#2E7D32",
      "Sick" = "#F9A825",
      "Sicker" = "#E64A19",
      "Death" = "#6D4C41"
    )
  ) +
  scale_legend_icon(size = 8) +
  theme_pop(base_size = 16) +
  theme(
    legend.position = "bottom",
    legend.title = element_blank(),
    plot.title = element_text(color = "black", face = "bold", hjust = 0.5),
    plot.subtitle = element_text(color = "black", hjust = 0.5),
    plot.caption = element_text(color = "black")
  ) +
  labs(
    title = "Sick-Sicker Cohort Markov Model \u00b7 Age: {closest_state} years",
    subtitle = "Cohort simulated from age 40 to 100",
    caption = "Cohort starts Healthy at age 40. Each icon is ~0.25% of the cohort."
  ) +
  transition_states(
    states = age,
    transition_length = 1,
    state_length = 1,
    wrap = FALSE
  ) +
  ease_aes("linear")

anim <- animate(
  p_anim,
  nframes = length(unique(df_icons$age)) * 1,
  fps = 2,
  width = 900,
  height = 900
)

anim

# Optional: save the animation
#anim_save("sick_sicker_animation.gif", anim)
